Din-Rail Three Phase Digital Power Meter Current Meter With LCD screen

Place of Origin : Zhejiang, China

Brand Name : SUCHEN

Model Number : CN-3AA4P

Display Type : Analog and Digital

Phase : Three Phase

Measuring Energy Range : 10(100)A

Accuracy Class : 0.5

Output Voltage : 220v/230v/240v

Operating Temperature : -10℃~+55℃

Dimensions : 76*74*91mm(L*W*H)

Frequency : 45-65Hz

Display : LCD

Warranty : 3 Years

OEM : Avaliable

Rated Current : 1.5(6)A,5(30)A,5(60)A,10(40)A,10(60)A.20(80)A,30(100)A, etc.

Operation current range : 0.05Ib~ I max (Direct);0.02Ib~ I max (with CT)

Communication : RS485 Port MODBUS-RTU Protocol

Power consumption : Voltage Circuit ≤1.0W 5VA;Current Circuit ≤1VA(Ib)

Connection mode : 3-phase four wires,3- phase 3-wires, 1phase 2 wires.

Product name : Three-Phase Din Rail Current Meter With LCD screen

Packaging Details : 1. Standard export carton ,suitable for long distance transportation.
2. Can customized package with customer's design,carton,box,and tape
Din-Rail Type Digital Meter Three-Phase Din Rail Current Meter With LCD screen

Port : Shanghai/Ningbo

Supply Ability : 7000 Piece/Pieces per Week

Price : $16.54 - $26.45/pieces
